Trouble with 3d Maps and Models - New to this

WebODM
1

I’m new to this. I’m having trouble with viewing 3d maps and models. Having trouble with blank spots with georeferenced Model and Textured Models. The sides of buildings are left blank, etc. I have shot the images 2 different ways with the same results. First at 75° and then at 60°. The 2nd project 433 images of 1/2 city block area so I’m pretty sure there is adequate overlapping.

Link to screen shot images: WebOMD 3d Images

Task Output:
Created on: 12/17/2021, 9:32:47 AM
Processing Node: node-odm-1 (auto)
Options: mesh-octree-depth: 12, use-3dmesh: true, pc-geometric: true, pc-quality: high, mesh-size: 300000
Average GSD: 1.11 cm
Area: 4,814.41 m²
Reconstructed Points: 142,662,092
